Antalya Sewerage System Construction and Water Network Rehabilitation Project (ru)

Brief Description of the Project :

The following contract packages are included in the scope of Antalya Sewerage System Construction and Water Network Rehabilitation Project, one of the sub-contracts (Contract M-12 / ASAT-C2) under the “Municipal Services Project” financed by IBRD credit provided to the Iller Bank.

Contract No: ASAT W6-2/S-24

Drinking Water Pipeline – total 66 km, Ø110 – Ø560 mm HDPE pipes

House Connections - total 3.5 km, Ø32 – Ø75 mm PE pipes

Total 20.757 m² asphalt paving, supply of valves in various diameters, valve chamber construction and highway crossing by horizontal boring

Contract No: ASAT W6-2/S-21

Drinking Water Pipeline – total 22 km, Ø110 – Ø800 mm HDPE pipes

House Connections - total 0.6 km, Ø32 – Ø75 mm PE pipes

Total 33.473 m² asphalt paving, supply of valves in various diameters, valve chamber construction and highway crossing by horizontal boring

Contract No: ASAT W6-2/S-11

Drinking Water Pipeline – total 159 km, Ø110 – Ø450 mm HDPE pipes

House Connections - total 102 km, Ø32 – Ø63 mm PE pipes

Total 44.992 m² asphalt paving, supply of valves in various diameters, and valve chamber construction.

Contract No: ASAT W9/A 41-R

Drinking Water Pipeline – total 119 km, Ø110 – Ø800 mm HDPE pipes

Wastewater Pipeline – total 67 km, Ø200 – Ø800 mm HDPE pipes

House Connections - total 33.4 km, Ø32 – Ø63 mm PE pipes

Total 114.971 m² asphalt paving, supply of valves in various diameters, and valve chamber construction, WW manholes and RTU panel rehabilitation.

Contract No: ASAT W10/A 42-R

Drinking Water Pipeline – total 101 km, Ø110 – Ø560 mm HDPE pipes

Wastewater Pipeline – total 84 km, Ø200 – Ø800 mm concrete pipes

House Connections - total 25.3 km, Ø32 – Ø63 mm PE pipes

Plot Connections – total 17.8 km, Ø150 – Ø200 mm PE pipes

Total 72.655 m² asphalt paving, supply of valves in various diameters, valve chamber construction and highway crossing by horizontal boring and WW manholes.

Contract No: ASAT W3/S-12

Drinking Water Pipeline – total 20 km, Ø110 – Ø630 mm HDPE pipes

Wastewater Pipeline – total 26.5 km, Ø400 – Ø1000 mm steel pipes

House Connections - total 13.4 km, Ø32 – Ø63 mm PE pipes

Plot Connections – total 17.8 km, Ø150 – Ø200 mm PE pipes

Total 19.824 m² asphalt paving, supply of valves in various diameters, valve chamber construction and highway crossing by horizontal boring and panel rehabilitation.

Scope of Services :

• Project Management,
• Preparation of detail design,
• Tender documentation as per FIDIC specifications,
• Technical support in tendering process and contract award,
• Construction supervision works,
• Supervision in defects liability period.
