Consultancy Services for Construction and Rehabilitation of Sewerage and Stormwater Networks in Denizli (ru)

Brief Description of the Project :

With reference to the “Municipal Services Project” financed by the IBRD credit provided to the Iller Bank, the Consultancy Services comprised review of final design, tender documentation and construction supervision for Sewerage Network, as one of the sub-contracts (Contract DEN2-C2). The following contract packages are within scope of the project:

Contract Package No: DEN2-W4

Wastewater Network – total 33 km, Ø 200 - 400 mm Concrete Pipes

Stormwater Network – total 7,3 km, Ø 300 - 1200 mm Concrete Pipes

Drinking Water Network – total 46 km, Ø100 - 700 mm Ductile Pipes

House Connections – total 33 km, Ø25 – 40 mm PE Pipes

Plot Connections – total 16 km, Ø150 mm Concrete Pipes

Contract Package No: DEN2-W5

Wastewater Network – total 32 km, Ø 200 - 600 mm Concrete Pipes

Stormwater Network – total 10 km, Ø 300 - 1600 mm Concrete Pipes

Drinking Water Network – total 39 km, Ø100 – 600 mm Ductile Pipes

House Connections – total 19 km, Ø25 – 40 mm PE Pipes

Plot Connections – total 14 km, Ø150 mm Concrete Pipes

Contract Package No: DEN2-W6

Wastewater Network – total 27 km, Ø 200 - 1000 mm Concrete Pipes

Stormwater Network – total 4.3 km, Ø 300 - 1000 mm Concrete Pipes

Drinking Water Network – total 36.5 km, Ø100 – 600 mm Ductile Pipes

House Connections – total 16 km, Ø25 – 40 mm PE Pipes

Plot Connections – total 8.5 km, Ø150 mm Concrete Pipes

Scope of Services :

• Project Management,
• Preparation of detail design,
• Preparation of tender documentation,
• Technical support in tendering process and contract award,
• Construction supervision services,
• Supervision services in defects liability period.
